Name: Flood Zones

Display Field: CREATOR_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: The Digital Flood Insurance Rate Map (DFIRM) Database depicts flood risk information and supporting data used to develop the risk data. The primary risk classifications used are the 1-percent-annual-chance flood event, the 0.2-percent-annual-chance flood event, and areas of minimal flood risk. The DFIRM Database is derived from Flood Insurance Studies (FISs), previously published Flood Insurance Rate Maps (FIRMs), flood hazard analyses performed in support of the FISs and FIRMs, and new mapping data, where available. The FISs and FIRMs are published by the Federal Emergency Management Agency (FEMA). The file is georeferenced to earth's surface using the State Plane projection and coordinate system.The specifications for the horizontal control of DFIRM data files are consistent with those required for mapping at a scale of 1:12,000. ** The following work was subsequently performed on May 13, 2008 by Lee County GIS Department. The flood polygons were intersected with the BFE lines to create discrete polygons, to which the BFE was assigned. A new field FLOODZONE was added and populated with a concatenation of FLD_ZONE and BFE. The resulting dataset is Lee_fld_haz_ar, which was imported into SDE. On July 16, 2008 records with a blank FLOODWAY value were populated with "OUTSIDE" to clarify results on LeeSpInS' District Query. ** Structures that have been issued Letters of Map Change (LOMC) are added to this feature class periodically.

Copyright Text: FEMA, Lee County Planning

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 565122.8710703291
YMin: 720669.6695940718
XMax: 799452.2495234944
YMax: 892869.7986183241
Spatial Reference: 102659  (2237)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: FLD_ZONE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: VE
  Label: VE
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 0, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: CAZ
  Label: Coastal A Zone
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [132, 0, 168, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: AE
  Label: AE
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 115, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: AH
  Label: AH
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [223, 117, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: AO
  Label: AO
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 170, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: A
  Label: A
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [117, 255, 117, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: X (shaded)
  Label: X (shaded)
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [135, 68, 68, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
• Value: X
  Label: X
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 255, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 255, 255, 255]
  Width: 1
Transparency: 44
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [52, 52, 52, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: baseline
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 9
Font Family: Arial Nova
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 50000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• FLD_ZONE ( type: esriFieldTypeString, alias: FLD_ZONE, length: 10 , Coded Values: [VE: VE] , [A: A] , [AE: AE] , ...6 more... )
• FLOODWAY ( type: esriFieldTypeString, alias: FLOODWAY, length: 50 , Coded Values: [Outside: Outside] , [Able Canal: Able Canal] , [Bedman Creek: Bedman Creek] , ...63 more... )
• SFHA_TF ( type: esriFieldTypeString, alias: SFHA_TF, length: 1 , Coded Values: [T: True] , [F: False] )
• STATIC_BFE ( type: esriFieldTypeDouble, alias: STATIC_BFE )
• DEPTH ( type: esriFieldTypeDouble, alias: DEPTH )
• SOURCE_CIT ( type: esriFieldTypeString, alias: SOURCE_CIT, length: 11 )
• FLOODZONE ( type: esriFieldTypeString, alias: FLOODZONE, length: 40 )
• FLDZON_NUM ( type: esriFieldTypeSmallInteger, alias: FLDZON_NUM )
• FIRMCommunity ( type: esriFieldTypeString, alias: FIRMCommunity, length: 6 , Coded Values: [125124: Unincorporated Lee County] , [120680: City of Bonita Springs] , [125095: City of Cape Coral] , ...5 more... )
• CREATOR_NAME ( type: esriFieldTypeString, alias: CREATOR_NAME, length: 100 )
• CREATE_DATE ( type: esriFieldTypeDate, alias: CREATE_DATE, length: 8 )
• EDITOR_NAME ( type: esriFieldTypeString, alias: EDITOR_NAME, length: 100 )
• EDIT_DATE ( type: esriFieldTypeDate, alias: EDIT_DATE, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• Zone_Subty ( type: esriFieldTypeString, alias: Zone Subtype, length: 100 , Coded Values: [0.2 PCT ANNUAL CHANCE FLOOD HAZARD: 0.2 PCT ANNUAL CHANCE FLOOD HAZARD] , [0.2 PCT ANNUAL CHANCE FLOOD HAZARD IN COASTAL ZONE: 0.2 PCT ANNUAL CHANCE FLOOD HAZARD IN COASTAL ZONE] , [0.2 PCT ANNUAL CHANCE FLOOD HAZARD IN COMBINED RIVERINE AND COASTAL ZONE: 0.2 PCT ANNUAL CHANCE FLOOD HAZARD IN COMBINED RIVERINE AND COASTAL ZONE] , ...5 more... )
• Source_GlobalID ( type: esriFieldTypeGUID, alias: Source Global ID, length: 38 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
